Year
2022
Make
Yizumi
Model
UN800A5S
Description
Lots of stock for sell, Contact us for good price.
Reference #
Y-Y
Price
GET A QUOTE
INQUIRE NOW

Used YIZUMI UN800A5S injection molding machine, 8000kN clamping force with four-screw options for mass-producing large-size heavy-duty plastic parts.

Main Specifications
Screw Diameter (mm)
100
lnjection Weight (PS)(g)
3468.3
lnjection Rate (PS)(g/s)
666
Clamping Force (kN)
8000
Dist. Between Tie Bars (HxV)(mm)
1000×1000
Machine Dimension (l x w x h)
10.51×2.38×2.73
Machine Weight (t)
40
YUZUMI UN800A5S Download PDF Now
This is a used YIZUMI UN800A5S injection molding machine with four screw options(A:90mm, B:100mm, C:110mm, D:120mm).
Max clamping force:8000 kN. PS shot weight:2930.6g(A)/3468.3g(B)/4042.7g(C)/4667g(D), max injection pressure 212.8/172.4/143.1/121.5 MPa.
Tie-bar space 960×910 mm, mould height 350-960 mm, ejector force 230 kN for smooth demolding of large plastic workpieces.

Suitable Products:
‑Daily plastics: extra‑large storage containers, heavy‑duty furniture components, thick‑wall large‑size household articles
‑Auto parts: large‑scale auto interior‑exterior assemblies, full‑size bumper modules, heavy‑load vehicle structural parts
‑Logistics & Industrial: heavy‑duty large pallets, big‑volume turnover crates, oversized industrial equipment housings
‑Home appliance & Packaging: extra‑large appliance shells, big‑capacity packaging containers, heavy‑duty large‑size engineering plastic parts
