This is a used JU5500/3100SE injection molding machine equipped with B‑spec screw (80 mm). Clamping force: 5500 kN (550 ton). Theoretical injection volume: 1860 cm³, injection weight 1692 g, max injection pressure 167 MPa. Tie‑bar inner dimension 920×830 mm, mold thickness range 350‑900 mm, ejection force 110 kN for stable part demolding.
Suitable Products:
‑ Daily household plastics: large thick-wall storage containers, oversized kitchen & bathroom accessories and large daily plastic housings
‑ Electronic components: large home appliance shells, industrial electrical enclosures and thick-wall structural parts
‑ Auto plastic parts: medium-large automotive interior and exterior trims, thick plastic brackets, vehicle protective covers and fastening parts
‑ Packaging parts and heavy-duty large-scale industrial plastic fittings
Home
New Arrived, Used HAITIAN Injection Molding Machines Used 550 Ton JU5500/3100SE Injection Molding Machine | B‑Screw 80mm, 1692g PS Shot Weight
Used 550 Ton JU5500/3100SE Injection Molding Machine | B‑Screw 80mm, 1692g PS Shot Weight
| Year | 2022 |
| Make | Haitian |
| Model | JU5500/3100SE |
| Description | Lots of stock for sell, Contact us for good price. |
| Reference # | Y-H |
Price
GET A QUOTE
Used 550‑ton Haitian JU5500/3100SE two‑plate injection molding machine with 80mm B‑spec screw. Ideal for mass‑producing large thick‑wall household, automotive and heavy‑duty industrial plastic parts.
Main Specifications
| Screw Diameter (mm) | 80 |
| lnjection Weight (PS)(g) | 1692 |
| lnjection Rate (PS)(g/s) | 501 |
| Clamping Force (kN) | 5500 |
| Dist. Between Tie Bars (HxV)(mm) | 920×830 |
| Machine Dimension (l x w x h) | 7.20×2.35×2.37 |
| Machine Weight (t) | 21 |
